eSurvey GEOSolution Post-Processing Software

With eSurvey’s GEOSolution software allows you to post process all of your data in one convenient package. Whether you are doing static work, dynamic stop and go work, or need to perform network adjustments, GEOSolution is the solution for you.

Additional product info

Product details

  • Windows Based
  • 7 and 4 Parameter Coordinate Systems
  • Geoid Models
  • Static Processing
  • Dynamic Processing
  • “Stop and Go” Processing
  • Supports Network Adjustment

Package includes

  • GEOSolution Software License

Description

eSurvey is not only an industry leader in hardware solutions, but also in terms of software packages. With eSurvey’s software solutions you are ensured of an easy to use easy to understand solution that does everything you need it to at a fraction of the cost.



With eSurvey’s GeoSolution, you get a high performance post-processing software package with all the features you expect. There is no need to use multiple different software packages to process different data sets. In GEOSolutions you can process your static data, dynamic “stop and go” data as well as perform any network adjustments. This is the package that does everything you need it to.

FAQs

eSurvey GEOSolution is Windows-based GNSS post-processing software designed to calculate precise positions from recorded satellite observation data. It supports static and kinematic processing, including stop-and-go workflows, as well as GNSS baseline calculations and network adjustments. It is useful for surveyors who need to process field observations, review measurement quality, and produce coordinate results and adjustment reports after data collection.

Static processing is used when GNSS receivers remain stationary while collecting observations at survey points. Stop-and-go processing is a kinematic method in which a rover moves between points while maintaining satellite observations, allowing positions to be calculated during post-processing. GEOSolution supports both workflows, so the appropriate method depends on how the field observations were collected.

Yes. GEOSolution supports standard RINEX observation files, which makes it possible to process compatible data collected with different GNSS receiver brands. It also supports its own .dat observation format and includes a RINEX conversion tool. Proprietary receiver files may need to be converted before processing, so confirm that your receiver’s specific data format is supported.

The manufacturer lists support for GPS, GLONASS, BeiDou, and Galileo observations. Using data from multiple supported satellite constellations can provide more available satellite measurements for baseline processing. The actual signals and observations available depend on the receiver, its configuration, and the data recorded during the survey.

Yes. GEOSolution can perform 2D, 3D, and elevation network adjustments using processed GNSS baselines and known control point coordinates. The software can generate adjustment reports and coordinate results for reviewing the network. Surveyors still need to assess the adjustment results, check control information, and verify that the selected coordinate system and survey tolerances are appropriate for the project.

Yes. GEOSolution includes tools for evaluating processed GNSS baselines using quality indicators such as RATIO and RMS. It also supports closed-loop verification and repeated baseline comparisons to help identify inconsistent or unreliable results before network adjustment. These checks allow surveyors to review the quality of their observations and assess whether the processed data meets project requirements.

Yes. GEOSolution processes GNSS observation files collected in the field, so a live RTK correction connection is not required during data collection. Depending on the processing method, you need observation data from a base receiver or a suitable reference station. The software also supports the use of IGS and CORS reference data, along with precise ephemeris files, for post-processing.

GEOSolution supports several output formats for survey coordinates and processing results, including DAT, DXF, and KML. It can also generate baseline solution and network adjustment reports. Customizable output settings allow users to select the coordinate information and other fields they need for subsequent surveying, CAD, or mapping workflows.

GEOSolution is desktop software designed for Windows computers. eSurvey provides separate 32-bit and 64-bit installation packages, allowing users to select the appropriate version for their system. Check the software’s current operating-system requirements before installation, particularly when using a newer Windows environment.

The package includes one GEOSolution software license for post-processing GNSS observations and performing network adjustments. The license covers the software itself; GNSS receivers, field data collectors, and other surveying hardware are not included. You will need a compatible Windows computer and suitable GNSS observation data to use the software.
